GAIL PRODUCTS

Low Pressure Pumps (1,000 PSI to 11,000 PSI)	High Pressure Pumps (Up to 100,000 PSI)	Pump Parts Diagram & Numbered Parts List
Series 625 Series 840 Series 6000 Series 10000 Series 11000	Series 10RBA Series 15RBA Series 20RBA Series 30RBA RBA M60	Click here to view the pump parts diagram. Click here to view the pump parts list.

SERIES	HEIGHT	WIDTH	LENGTH	WEIGHT	RPM's	PSI	VOLUME/min
625	18cm	12cm	20cm	24lbs	350	600	8Gal
840	18cm	12cm	20cm	24lbs	400	800	9Gal
6000	18cm	14cm	23cm	30lbs	400	6000	21Gal
10000	18cm	14cm	21cm	28lbs	450	10000	24Gal
11000	18cm	14cm	23cm	30lbs	450	11000	25Gal
10RBA	22cm	16cm	24cm	41lbs	600	10000	35Gal
15RBA	22cm	16cm	24cm	41lbs	650	15000	42Gal
20RBA	24cm	18cm	24cm	48lbs	650	20000	45Gal
30RBA	24cm	18cm	24cm	48lbs	650	30000	50Gal
